NFC identification function supports the interpretation of M1, Type-A, Type-B and various common IC cards
The maximum NFC card reading distance is 6cm.
Active induction scanning mode, seamless switching of scanning.
Voice broadcast and 6500K light source lighting.
Efficient work performance -- decoded and sent within 100ms.
High speed camera optical technology--50cm/s motion tolerance , don't need to be stationary to scan 30w pixel.
Optional scanning configuration for strong light and backlight environment.
Support fuzzy, damaged, reversed, color, print problem, incomplete 1D/2D barcode on paper and 1D/2D barcode on screen.
Applicable to restaurant, supermarket, hotel, governments, library, retail store and other intelligent scenarios.
DESCRIPTION
| Read Parameters | Image sensor | 640 x 480 CMOS@30fps |
| Perspective | Horizontal 53 °, vertical 41 ° | |
| Reading angle | Rotation: 360°, Pitch: ±45°, Deflection: ±45° | |
| Reading code system | 2D: QR Code、PDF417、DataMatrix (ECC200) | |
1D: EAN13、EAN8、UPC-A、UPC-E0、UPC-E1、Code128、Code39、Code93、CodaBar 、 Interleaved 2 of 5、Industrial 25、Matrix 2 of 5、Code11、 MSI Plessey、RSS-14、RSS-Limited、RSS-Expanded | ||
| Depth of Field | EAN13: 0 ~ 110mm (13mil) | |
| Code128: 0 ~ 150mm (20mil) | ||
| Code39: 0 ~ 30mm(5mil) | ||
| WeChat payment code: 0 ~ 250mm (5 inch screen mobile phone) | ||
| Reading accuracy | 1D ≥ 5mil, 2D ≥ 10mil | |
| Read tips | BEEP | |
| Non-connection Parameters | Meet the standards | ISO14443 TypeA/ B ,M1 |
| Card reading distance | 0 ~ 6 cm | |
| Function | Read sector, read block | |
| Output | Can set decimal forward or reverse output, and hexadecimal forward or reverse output | |
| Physics Parameters | Lights | 4 LEDs (6500K) |
| Operating voltage | USB 5V | |
| Operating current | 280mA | |
| Weight | 255g | |
| Line length | 1.5 meters | |
| Appearance size | 130mm L*109mm W*111.5mm H | |
| Material | ABS | |
| Communication port | USB-TypeA HID-KBW | |
| Use Environment | Operating temperature | -20 ℃ ~ 55 ℃ |
| Storage temperature | -40 ℃ ~ 70 ℃ | |
| Working humidity | 5% RH ~ 95% RH (no condensation) | |
| Vibration | 5~200Hz,10Grms,3axes,1.5Hr | |
| Fall | Can withstand 1.2 meters of falling to the concrete floor |
